Session Initiation Protocol (SIP) Attacks: A Red Team Perspective

SIP, or Session Initiation Protocol, is a signaling protocol used to create, modify, and terminate real-time sessions between two or more participants. Think of it as the "phone number" of the internet for communication services. Its primary function is to handle the setup and teardown of communication sessions, but not the actual data transfer itself. This separation of control and data makes it incredibly flexible. The reason for its widespread adoption lies in this flexibility and its foundation on an open standard that is text-based and easy to extend. Unlike proprietary systems, SIP allows different vendors' devices and software to communicate with each other seamlessly. This has led to its use in a vast range of applications, including Voice over IP (VoIP) calls, video conferencing, instant messaging, and even online gaming, making it a cornerstone of modern unified communications.

This article provides a comprehensive overview of SIP security weaknesses, practical exploitation methods, and red team use cases.


Understanding SIP

SIP is an application-layer protocol that establishes, modifies, and terminates multimedia sessions. Commonly, SIP operates over UDP (port 5060) or TCP (port 5060/5061).

A typical SIP request looks like this:


INVITE sip:[1001@pbx.example.com](mailto:1001@pbx.example.com) SIP/2.0
Via: SIP/2.0/UDP attacker.example.com;branch=z9hG4bK776asdhds
Max-Forwards: 70
From: "Alice" [sip\:alice@example.com](sip:alice@example.com);tag=1928301774
To: [sip:1001@pbx.example.com](sip:1001@pbx.example.com)
Call-ID: [a84b4c76e66710@pc33.example.com](mailto:a84b4c76e66710@pc33.example.com)
CSeq: 314159 INVITE
Contact: [sip\:alice@attacker.example.com](sip:alice@attacker.example.com)
Content-Type: application/sdp
Content-Length: 142

The Session Initiation Protocol (SIP) is the backbone of most Voice over IP (VoIP) communications. It is widely used in IP telephony, video conferencing, instant messaging, and other real-time communication services.
However, despite its importance, SIP is often poorly secured, making it a prime target for attackers — and a valuable entry point for red teams.


Common SIP Attack Vectors

SIP Enumeration

Attackers can enumerate valid SIP extensions by sending REGISTER, OPTIONS, or INVITE requests and analyzing the server’s responses.

Example: Using svmap SIPVicious

svmap udp://pbx.example.com

This scans for active SIP devices.

SIP Brute-Force Attacks

Once valid extensions are found, attackers can brute-force credentials using tools like svwar or medusa.

Example: Brute-forcing SIP accounts

svwar -m INVITE -e100-200 pbx.example.com
medusa -h pbx.example.com -u 1001 -P passwords.txt -M sip

SIP Registration Hijacking

If authentication is weak, an attacker can register as a valid user and intercept calls.

Attack Flow:

  1. Attacker sends REGISTER request with victim’s username.
  2. SIP server updates location database to attacker’s IP.
  3. All future calls route to attacker.

SIP Message Manipulation (Call Hijacking)

Using tools like sipsak, an attacker can inject fake BYE or INVITE messages to drop or redirect calls.

Example: Sending a fake BYE request

sipsak -B -s sip:1001@pbx.example.com

SIP Toll Fraud

Attackers exploit SIP to route expensive international calls, causing financial loss to the target.

Denial of Service (DoS) via SIP Flood

Flooding SIP INVITE messages can overwhelm PBX servers.

Example with sipp

sipp -sf invite.xml pbx.example.com -r 1000 -m 10000

Red Team Use Cases

From a red team perspective, SIP attacks are valuable for:

Reconnaissance

  • Enumerating valid SIP extensions reveals internal phone structure.
  • Identifying PBX vendor/version via response headers.

Initial Access

  • Exploiting weak credentials to register as an internal extension.
  • Using compromised VoIP systems as pivot points into the corporate network.

Persistence

  • Backdoor SIP accounts for long-term call interception.
  • Deploying malicious dial plans on compromised PBX systems.

Impact Simulation

  • Demonstrating toll fraud or call recording to highlight real-world risk.
  • Simulating telecom-based ransomware (blocking outgoing calls until ransom is paid).

Defending Against SIP Attacks

From a blue team perspective:

  • Enforce strong authentication (SIP over TLS with SRTP).
  • Restrict SIP access to trusted IP ranges.
  • Implement rate limiting to prevent brute force.
  • Monitor for unusual call patterns (e.g., high-cost international calls).
  • Use SIP-aware firewalls (e.g., fail2ban with SIP rules).

Summary

SIP attacks remain a serious yet underestimated threat to organizations relying on VoIP. For red teams, SIP can serve as a low-noise foothold into sensitive networks. For defenders, implementing proper authentication, encryption, and monitoring is essential to mitigate these risks.


***
